1. Introduction — What Purification Actually Means

Filtration removes particles. Purification makes water safe. The distinction matters because most consumer products do one and claim the other.

Water contaminants fall into three categories:

  • **Biological:** Bacteria, viruses, protozoan cysts, parasitic worms
  • **Chemical:** Pesticides, herbicides, pharmaceuticals, industrial solvents, heavy metals (lead, arsenic, mercury)
  • **Physical/dissolved solids:** Sediment, turbidity, dissolved minerals, salts, total dissolved solids (TDS)

A 0.2-micron ceramic filter is excellent against bacteria and protozoa. It does nothing against viruses (0.02–0.3 microns), dissolved arsenic, or pharmaceutical residues. Boiling kills every biological threat but concentrates chemical contaminants — the water volume drops, the chemicals stay. Activated carbon adsorbs chlorine and many organic chemicals but passes bacteria freely.

No single method handles all three categories. That is the central fact of water treatment, and the reason this document covers stacking methods rather than recommending one magic solution.

The practical standard: drink water that has passed through at least two treatment methods from different categories. One biological kill step. One physical or chemical removal step. Test periodically to confirm both are working.

2. Biological Threats — What Lives in Untreated Water

The three classes of biological contaminants differ by size, and size determines which treatment methods work.

Pathogen Size Comparison Table

| Pathogen Type | Example Organisms | Size Range | Boiling | Chlorine | 0.2µm Filter | 0.02µm Filter | UV | |---|---|---|---|---|---|---|---| | **Protozoan cysts** | *Giardia lamblia*, *Cryptosporidium parvum* | 4–15 µm | Yes | Partial* | Yes | Yes | Yes | | **Bacteria** | *E. coli*, *Salmonella*, *Vibrio cholerae*, *Campylobacter* | 0.2–5 µm | Yes | Yes | Yes | Yes | Yes | | **Viruses** | Hepatitis A, Norovirus, Rotavirus, Adenovirus | 0.02–0.3 µm | Yes | Yes | No | Yes | Yes | | **Parasitic worms** | *Schistosoma*, *Ascaris* eggs | 20–80 µm | Yes | Partial | Yes | Yes | Yes |

*\*Cryptosporidium is highly resistant to chlorine at standard drinking water doses. The CT value (concentration × time) required is 15,300 mg·min/L — roughly 1,000 times the dose needed for bacteria (CDC, 2012). Chlorine dioxide is effective; standard chlorine is not reliable against Crypto.*

**Giardia** causes the majority of waterborne illness from backcountry water sources in North America. Infection dose is as low as 10 cysts. Cysts survive weeks in cold water. Any filter rated at 1 micron or below removes Giardia reliably.

**Cryptosporidium** is the harder target. Cysts are 4–6 microns but resist chlorine at any practical dose. Filtration at 1 micron, boiling, or UV are the reliable options.

**Viruses** are the gap in most portable filtration. Standard ceramic and hollow-fiber filters rated at 0.1–0.2 microns pass viruses. In wilderness settings in developed countries, viral waterborne illness is rare. In developing countries or flood/sewage contamination scenarios, a viral kill step (boiling, chlorine, or UV) is essential.

3. Boiling — The Oldest and Most Reliable Biological Kill

Boiling is the only method that reliably kills all biological pathogens regardless of water clarity, pH, or contaminant load. No organism survives 100°C.

The common advice to boil for 10 minutes is excessive. Pasteurization — the temperature at which pathogens die — occurs at 65°C (149°F) for 6 minutes. By the time water reaches a rolling boil at 100°C, every pathogen including bacterial spores is dead or dying. The CDC and WHO both recommend bringing water to a rolling boil for 1 minute at elevations below 2,000 meters (6,562 feet).

Boiling Time by Altitude

| Elevation | Boiling Point | Recommended Boil Time | Notes | |---|---|---|---| | Sea level – 2,000m (0–6,562 ft) | 100–93°C (212–200°F) | 1 minute rolling boil | All pathogens killed at these temps | | 2,000–5,000m (6,562–16,404 ft) | 93–83°C (200–181°F) | 3 minutes rolling boil | Lower boiling point requires longer exposure | | Above 5,000m (16,404 ft) | Below 83°C (181°F) | 5 minutes rolling boil | Rare scenario — high alpine/mountaineering |

Energy Cost

Bringing 1 liter of water from 20°C to 100°C requires approximately 335 kJ (80 kcal). In practical terms:

  • **Propane:** 0.02 lbs per liter ($0.01 at bulk prices)
  • **Wood fire (open):** ~0.5–1 kg of dry wood per liter (highly inefficient, ~10% thermal transfer)
  • **Rocket stove:** 0.2–0.3 kg of dry wood per liter (35% thermal transfer)
  • **Electric kettle:** 0.1 kWh per liter ($0.01–0.02)

Limitations of Boiling

Boiling does not remove:

  • Dissolved chemicals (pesticides, herbicides, pharmaceuticals)
  • Heavy metals (lead, arsenic, mercury, cadmium)
  • Dissolved solids (salts, minerals, TDS)
  • Turbidity (sediment, particulates)

Boiling concentrates all of the above. If source water contains 50 ppb arsenic, boiling it down to half volume produces 100 ppb arsenic. In areas with known chemical contamination, boiling alone makes the water worse.

**Practical application:** Boiling is the gold standard for biological threats and the correct emergency method when you have fuel and no other treatment. Pair it with activated carbon filtration if chemical contamination is possible.

4. Chemical Treatment — Chlorine, Iodine, and Chlorine Dioxide

Chemical disinfection works by oxidizing cell membranes and disrupting pathogen DNA/RNA. Three chemicals dominate field and emergency use.

4a. Chlorine — The Workhorse

Chlorine is available in three practical forms for water treatment:

| Form | Active Ingredient | Available Chlorine | Shelf Life | Notes | |---|---|---|---|---| | **Calcium hypochlorite (dry granular)** | Ca(ClO)₂ | 65–73% | 10+ years (sealed, dry, cool) | Best long-term storage form | | **Sodium hypochlorite (liquid bleach)** | NaClO | 5.25–8.25% | 6–12 months before significant degradation | Most accessible; degrades in heat/light | | **Pool shock (calcium hypochlorite)** | Ca(ClO)₂ | 65–73% | 10+ years | Same as granular; ensure no algaecides or clarifiers added |

**Calcium hypochlorite** is the superior storage form. Dry granular product retains >90% available chlorine after 10 years when stored sealed, cool, and dark (EPA Emergency Disinfection Guidelines). Liquid bleach loses roughly half its strength annually at room temperature.

#### Chlorine Dosing Table

| Water Clarity | Sodium Hypochlorite (5.25% bleach) | Calcium Hypochlorite (granular, 68%) | Contact Time | |---|---|---|---| | Clear water | 2 drops per liter (0.1 mL) | 1/8 teaspoon per gallon of stock solution* | 30 minutes | | Cloudy/turbid water | 4 drops per liter (0.2 mL) | 1/4 teaspoon per gallon of stock solution* | 60 minutes |

*\*Stock solution: Dissolve 1 level teaspoon (approximately 7g) of calcium hypochlorite granules in 2 gallons (7.5L) of water. This produces a ~500 ppm chlorine solution. Use this stock solution at the doses above.*

**Residual test:** After contact time, treated water should smell faintly of chlorine. If it does not, repeat the dose and wait another 30 minutes. A free chlorine residual of 0.2–0.5 mg/L (ppm) confirms adequate treatment. Pool test strips or DPD-1 reagent kits measure this accurately.

**pH matters.** Chlorine effectiveness drops sharply above pH 8.0. At pH 6.5, hypochlorous acid (the active form) constitutes ~90% of free chlorine. At pH 8.5, it drops to ~10%. Alkaline water requires higher doses or longer contact times.

4b. Iodine

Iodine works against bacteria, viruses, and Giardia. It is less effective against Cryptosporidium.

| Form | Dose | Contact Time | Notes | |---|---|---|---| | **Iodine tablets (tetraglycine hydroperiodide)** | 1 tablet per liter (clear), 2 tablets (turbid) | 30 minutes (warm water), 60 minutes (cold <5°C) | Potable Aqua is the common brand | | **2% tincture of iodine** | 5 drops per liter (clear), 10 drops (turbid) | 30 minutes | Widely available at pharmacies | | **10% povidone-iodine (Betadine)** | 4 drops per liter | 30 minutes | Less taste impact; lower free iodine |

**Limitations:** Iodine is not recommended for long-term use (more than 3 weeks continuous), pregnant women, or individuals with thyroid conditions. It gives water a noticeable taste that vitamin C (ascorbic acid) can neutralize after the contact time is complete — add a pinch after treatment, not before.

Iodine does not reliably kill Cryptosporidium at field doses.

4c. Chlorine Dioxide (ClO₂)

Chlorine dioxide is the only chemical disinfectant reliable against all three biological categories including Cryptosporidium. It works across a wider pH range than chlorine and produces fewer disinfection byproducts.

| Form | Dose | Contact Time | Notes | |---|---|---|---| | **Aquamira drops (Part A + Part B)** | 7 drops each per liter, mix 5 minutes before adding to water | 15 minutes (bacteria), 30 minutes (viruses), 4 hours (Crypto) | Two-part system generates ClO₂ on demand | | **Potable Aqua ClO₂ tablets** | 1 tablet per liter | 15 minutes (bacteria), 30 minutes (viruses), 4 hours (Crypto) | Single tablet, no mixing required |

The 4-hour wait for Cryptosporidium makes chlorine dioxide impractical as a sole treatment when Crypto is a concern. Pair it with filtration at 1 micron or below to handle Crypto mechanically while ClO₂ handles viruses.

5. Filtration — Physical Barriers by Pore Size

Filtration removes contaminants by size exclusion, adsorption, or both. The critical number is pore size, measured in microns.

Filter Pore Size and What Each Removes

| Pore Rating | Removes | Misses | Common Filter Types | |---|---|---|---| | **5 µm** | Sediment, large parasites, turbidity | Bacteria, viruses, chemicals | Sediment pre-filters, wound string cartridges | | **1 µm** | Protozoa (Giardia, Crypto), most bacteria | Smaller bacteria, all viruses, chemicals | Some ceramic filters, depth cartridges | | **0.2 µm (absolute)** | All bacteria, all protozoa, parasitic eggs | Viruses, dissolved chemicals, heavy metals | Ceramic candle filters, hollow fiber | | **0.1 µm** | All bacteria, all protozoa | Viruses, dissolved chemicals | Sawyer MINI, LifeStraw | | **0.02 µm** | All bacteria, protozoa, AND most viruses | Dissolved chemicals, heavy metals, TDS | Sawyer Select S3, ultrafiltration | | **0.001 µm (1 nm) — Reverse Osmosis** | Virtually everything including dissolved salts, heavy metals, most chemicals | Some volatile organic compounds (VOCs) | RO membranes |

5a. Ceramic Filters

Ceramic candle filters (Doulton, British Berkefeld, Potters for Peace) use diatomaceous earth or fired clay with pore sizes of 0.2–0.9 microns. The outer surface traps bacteria and protozoa. When flow slows, scrub the exterior with a clean brush to remove the biofilm and restore flow.

**Lifespan:** 6–12 months of daily use for a family of four, or approximately 1,000–2,000 gallons per element. Some high-quality candles (Doulton Ultracarb) include an activated carbon core for chemical reduction.

**DIY note:** Colloidal silver-impregnated ceramic pot filters (Filtron design) can be manufactured locally using local clay, sawdust (burned out during firing to create pores), and colloidal silver coating. The Potters for Peace model has been deployed in over 50 countries.

5b. Activated Carbon

Activated carbon works by adsorption — chemicals bind to the carbon surface rather than being blocked by pore size. It removes:

  • Chlorine and chloramine
  • Many pesticides and herbicides
  • Volatile organic compounds (VOCs)
  • Some pharmaceutical residues
  • Taste and odor compounds

It does **not** reliably remove bacteria, viruses, heavy metals, nitrates, or dissolved salts.

Carbon types differ:

  • **Granular activated carbon (GAC):** Lower cost, slower flow, larger systems. Good for whole-house filters.
  • **Carbon block:** Higher density, better chemical removal, slower flow. Used in countertop and under-sink systems.
  • **Coconut shell carbon:** Higher iodine number (surface area), better VOC adsorption than coal-based carbon.

**Exhaustion:** Carbon adsorption capacity is finite. Once the binding sites saturate, contaminants pass through unimpeded. Replacement schedules are not arbitrary — they depend on contaminant load. A carbon filter in rural well water may last a year. The same filter on municipal water with chloramine treatment may exhaust in 3–4 months.

5c. Biosand Filters (Manz Design)

The biosand filter (BSF) is the most cost-effective water treatment technology ever field-tested. Developed by Dr. David Manz at the University of Calgary, it uses layered sand and gravel in a concrete or plastic container. A biological layer (*schmutzdecke*) develops on the top sand surface over 2–3 weeks, actively consuming pathogens.

**Performance (CAWST, 2012; WHO):**

  • Bacteria: 90–99% removal
  • Protozoa: >99% removal
  • Viruses: 70–99% removal (varies with schmutzdecke maturity)
  • Turbidity: 85–95% removal
  • Iron: 90–95% removal

**Lifespan:** 20+ years with no replacement parts. The sand never needs replacing. When flow drops below 0.4 L/min, swirl and discard the top 1–2 cm of sand. The schmutzdecke regenerates in 1–2 weeks.

**Limitations:** Does not remove dissolved chemicals, heavy metals, or TDS. Does not work well with highly turbid water (pre-settle or pre-filter first). Requires consistent daily use to maintain the biological layer — if left unused for weeks, the schmutzdecke dies and must regrow.

5d. Hollow Fiber Filters

Hollow fiber technology uses bundles of tiny U-shaped tubes with pore sizes of 0.1–0.02 microns. Water is pulled or pushed through the tube walls; pathogens are trapped on the outer surface.

| Product | Pore Size | Flow Rate | Lifespan | Removes Viruses? | |---|---|---|---|---| | **Sawyer MINI** | 0.1 µm (absolute) | 0.5 L/min (gravity) | 100,000+ gallons (backwash maintained) | No | | **Sawyer Squeeze** | 0.1 µm (absolute) | 1.7 L/min (squeeze) | 100,000+ gallons | No | | **LifeStraw Personal** | 0.2 µm | N/A (sip) | 1,000 gallons | No | | **LifeStraw Community** | 0.2 µm + ultrafiltration | 12 L/hr (gravity) | 26,000+ gallons | Yes (0.02 µm membrane) | | **Sawyer Select S3** | 0.02 µm | 0.5 L/min | Replaceable foam pre-filter | Yes | | **MSR Guardian** | 0.02 µm (hollow fiber) | 2.5 L/min (pump) | 10,000 liters | Yes |

**Backwashing:** Hollow fiber filters must be backflushed regularly. The Sawyer system includes a syringe for this — push clean water backwards through the filter to clear trapped debris from the fibers. Failure to backwash leads to permanent flow loss.

**Freezing destroys hollow fiber filters.** Water trapped in the fibers expands and ruptures the tube walls, creating invisible pathways that pass pathogens. If a hollow fiber filter has frozen, replace it. There is no way to test for freeze damage in the field.

5e. Reverse Osmosis (RO)

RO membranes operate at 0.0001–0.001 microns (1–10 angstroms). They reject 95–99% of dissolved solids, heavy metals, salts, and most chemical contaminants. An RO system is the only filtration method that removes dissolved lead, arsenic, fluoride, nitrates, and sodium from water.

**Downsides:**

  • Wastes 2–4 gallons of water per gallon produced (reject water)
  • Requires municipal water pressure (40–80 psi) or a booster pump
  • Membranes cost $30–80 and need replacement every 2–3 years
  • Strips beneficial minerals (calcium, magnesium) — remineralization is often added
  • Slow production rate: 50–100 gallons per day for residential systems

**Practical application:** RO is the right choice for households with known chemical contamination (agricultural runoff, industrial pollution, high arsenic or lead). It is overkill and wasteful for biologically clean water that just needs taste improvement.

6. UV Treatment — Light as Disinfectant

Ultraviolet radiation at 254 nm (UV-C) damages pathogen DNA, preventing replication. It kills bacteria, viruses, and protozoa including Cryptosporidium — which resists chlorine but not UV.

UV Dose Requirements

| Target | UV Dose Required | Log Reduction | |---|---|---| | *E. coli* | 6.6 mJ/cm² | 4-log (99.99%) | | *Giardia lamblia* cysts | 2–5 mJ/cm² | 3-log (99.9%) | | *Cryptosporidium parvum* oocysts | 12 mJ/cm² | 4-log (99.99%) | | Hepatitis A virus | 30 mJ/cm² | 4-log | | Adenovirus (most UV-resistant virus) | 186 mJ/cm² | 4-log | | **EPA standard for POU devices** | **40 mJ/cm²** | **4-log for most pathogens** |

6a. SODIS — Solar Disinfection

SODIS uses UV-A radiation from sunlight passing through PET (polyethylene terephthalate) plastic bottles to inactivate pathogens. Developed and validated by EAWAG/SANDEC (Swiss Federal Institute), it has been deployed for over 5 million users in developing countries.

**Protocol:** 1. Fill clear PET bottles (1–2 liter soda bottles) with water 2. If turbidity exceeds 30 NTU, pre-filter through cloth or settle overnight 3. Place bottles on a reflective surface (corrugated metal roof) in direct sunlight 4. Expose for 6 hours in full sun, or 2 consecutive days under cloudy conditions 5. Water is safe to drink directly from the bottle

**Performance:** 99.9% inactivation of E. coli, Salmonella, Shigella, and Vibrio cholerae at 6 hours full sun exposure (Wegelin et al., 1994; McGuigan et al., 2012). UV-A plus thermal heating (bottles reach 50–60°C on metal roofs) provides synergistic kill.

**Limitations:**

  • Does not work with glass bottles (glass blocks UV-A)
  • PET bottles must be clear, unscratched, and un-tinted
  • Turbidity above 30 NTU blocks UV penetration — pre-filter first
  • Does not remove chemicals or dissolved contaminants
  • Bottle size limited to 2 liters for adequate UV penetration
  • Bottles should be replaced every 6–12 months as plastic degrades

6b. UV-C Lamps and Devices

Portable UV-C devices (SteriPEN, CamelBak UV, UV wand systems) generate 254 nm UV-C radiation electrically. They treat 0.5–1 liter in 60–90 seconds.

**Requirements:**

  • Water must be clear (turbidity <5 NTU). Particles shield pathogens from UV exposure.
  • Battery-dependent — carry backup power or batteries
  • No residual disinfection — treated water can be recontaminated

**Whole-house UV systems** install inline after sediment and carbon pre-filtration. They operate continuously, require annual bulb replacement (~$40–80), and draw 40–80 watts. These are the standard for well water systems where bacterial contamination is the primary concern.

**UV does not remove anything from the water.** Dead pathogens remain in the water. Dissolved chemicals, heavy metals, and turbidity are unaffected. UV is a kill step only — pair it with filtration for complete treatment.

7. Distillation — The Only Method That Removes (Nearly) Everything

Distillation separates water from contaminants by evaporation and condensation. Water boils at 100°C; most dissolved solids, heavy metals, salts, and minerals stay behind in the boiling vessel. The steam condenses into a separate container as purified distillate.

Distillation removes:

  • All bacteria, viruses, and protozoa (killed by boiling)
  • Heavy metals (lead, arsenic, mercury, cadmium)
  • Dissolved salts and minerals
  • Nitrates, fluoride, and most inorganic compounds
  • Radiological contaminants

What Distillation Misses

Volatile organic compounds (VOCs) with boiling points below 100°C vaporize and recondense with the water. These include:

  • Benzene (boiling point 80°C)
  • Trichloroethylene/TCE (87°C)
  • Chloroform (61°C)
  • Some pesticide components

**Solution:** Install an activated carbon post-filter on the distillate outlet. Carbon adsorbs VOCs that co-distill with the water. This combination — distillation plus carbon — addresses virtually every contaminant category.

7a. Pot Stills (Countertop/DIY)

A basic water distiller is a pot with a lid that channels steam into a condensation coil or tube. Commercial countertop distillers produce 1 gallon in 4–6 hours using 800–1,500 watts.

**DIY construction:** A stainless steel pressure cooker with copper tubing coiled through a cold water bath. Steam exits through the pressure valve fitting, travels through the copper coil (which is submerged in cold water), and condenses into a collection jar. Total cost: $40–80 in materials.

**Energy cost:** Approximately 3 kWh per gallon of distilled water electrically, or roughly $0.30–0.45 per gallon at average US electricity rates.

7b. Solar Stills

Solar stills use sunlight to evaporate water inside a sealed transparent enclosure. Condensation collects on the underside of the glass or plastic cover and drains into a collection channel.

**Performance:** A well-designed ground-level solar still produces 0.5–1 liter per square meter per day in sunny conditions. This is low output. Solar stills are survival tools, not primary water sources.

**Basin still design:** Black-bottomed shallow basin, angled glass cover, condensation gutter at the low edge. Feed contaminated water into the basin. Sun heats the black bottom, water evaporates, condenses on the glass, runs down to the gutter. Distillate drips into a sealed container.

**Practical application:** Solar stills are appropriate for desalination of seawater in coastal survival scenarios, or for removing dissolved contaminants from small volumes when no energy source is available. They are not practical for daily household water production.

8. DIY Systems — Build Your Own Treatment

8a. Building a Biosand Filter

The Manz-design biosand filter is the most impactful DIY water treatment system. Construction requires no specialized skills.

**Materials:**

  • Concrete form or large plastic container (5-gallon bucket for personal use, 55-gallon drum for family use)
  • Clean sand (0.15–0.35 mm effective grain size — mason sand or play sand, washed)
  • Pea gravel (6–12 mm)
  • Small gravel (1–6 mm)
  • PVC pipe or copper tube for outlet
  • Diffuser plate (perforated plastic or metal plate)

**Layer structure (bottom to top):**

| Layer | Material | Depth | Purpose | |---|---|---|---| | 1 (bottom) | Pea gravel (6–12 mm) | 5 cm (2 in) | Drainage, supports upper layers | | 2 | Small gravel (1–6 mm) | 5 cm (2 in) | Transition layer, prevents sand migration | | 3 | Fine sand (0.15–0.35 mm) | 45–55 cm (18–22 in) | Primary filtration and biological treatment | | 4 (top) | Standing water above sand | 5 cm (2 in) | Protects schmutzdecke from drying | | 5 | Diffuser plate | — | Prevents pouring water from disturbing sand surface |

**Construction steps:** 1. Drill or cut outlet hole near the bottom of the container. Install PVC pipe with a 90-degree elbow inside, rising to 5 cm above the sand surface (this maintains the standing water level). 2. Wash sand thoroughly — fill a bucket with sand, add water, stir vigorously, pour off cloudy water. Repeat until water runs clear. This removes fine clay and silt that would clog the filter. 3. Layer gravel, then small gravel, then sand. Do not compact — let sand settle naturally with water. 4. Fill with water and let sand settle for 24 hours. 5. Place diffuser plate on top of sand surface. 6. Begin filtering water. The first 2–3 weeks of output should be discarded or used for non-drinking purposes while the schmutzdecke biological layer establishes.

**Operation:** Pour water slowly onto the diffuser plate. Filtered water exits the outlet pipe. Flow rate should be 0.4–1.0 L/min. Slower is more effective. Do not let the sand surface dry out — the biological layer dies without water cover.

8b. Building a Charcoal/Sand Gravity Filter

A simpler but less effective alternative to the biosand filter. Does not develop a biological layer and therefore has lower pathogen removal.

**Materials:**

  • Two 5-gallon buckets (food grade)
  • Coarse gravel, fine sand, activated charcoal (not briquettes — use lump hardwood charcoal crushed to pea size, or purchased granular activated carbon)
  • Cotton cloth or coffee filters
  • Spigot or tube for lower bucket

**Layer structure (in upper bucket with holes drilled in bottom):**

| Layer | Material | Depth | Purpose | |---|---|---|---| | 1 (bottom) | Cotton cloth/coffee filter | — | Prevents sand from passing through holes | | 2 | Fine sand | 10–15 cm (4–6 in) | Particulate filtration | | 3 | Activated charcoal | 10–15 cm (4–6 in) | Chemical adsorption (chlorine, VOCs, taste) | | 4 | Coarse sand/gravel | 5–8 cm (2–3 in) | Pre-filtration, removes large sediment | | 5 (top) | Cotton cloth | — | Diffuser, keeps layers undisturbed |

Water poured into the top bucket filters through all layers and drips into the lower collection bucket via the holes.

**This filter improves taste and clarity but does not reliably kill pathogens.** Treat filtered water with chlorine, boiling, or UV as a second step.

8c. Rainwater First-Flush Diverters

The first water off a roof during rain carries bird droppings, dust, pollen, insect debris, and atmospheric pollutants. A first-flush diverter captures and discards this initial flow before directing clean water to storage.

**Design principle:** A sealed vertical pipe on the downspout fills with the first flush. Once full, incoming water bypasses the pipe and flows to the storage tank. A small drain hole (1/16 inch) at the bottom of the diverter pipe slowly empties it between rains.

**Sizing:** 1 gallon of diverter volume per 100 square feet of roof area is the minimum standard. For a 1,000 sq ft roof, use a 10-gallon diverter pipe. In heavily polluted areas or near agriculture, double this volume.

**Construction:** A 4-inch PVC pipe, 4 feet long, holds approximately 2.5 gallons. Cap the bottom with a small drain hole. Tee into the downspout above the storage tank inlet. When the pipe fills, water rises past the tee and flows to storage.

9. Testing — How to Know Your Water Is Safe

Treating water without testing is guessing. Basic testing equipment is inexpensive and accessible.

Test Parameters and Methods

| Parameter | What It Indicates | Test Method | Cost | Frequency | |---|---|---|---|---| | **Total coliforms** | General bacterial contamination | Colilert (IDEXX) presence/absence test, Hach coliform test kit | $15–30 per test | Quarterly, or after any system change | | **E. coli** | Fecal contamination specifically | Colilert with Quanti-Tray, EC-MUG test | $15–30 per test | Quarterly, or after any system change | | **Free chlorine residual** | Adequate chlorine treatment | DPD-1 test strips or reagent drops, pool test kit | $8–15 for 50+ tests | Every treated batch | | **pH** | Affects chlorine efficacy, corrosion, taste | pH test strips, digital pH meter | $5–15 | Monthly | | **Turbidity** | Clarity; affects UV/chlorine effectiveness | Turbidity tube (visual, <$20), nephelometer (accurate, $200+) | $15–200 | Before treatment | | **TDS (total dissolved solids)** | Dissolved minerals, salts, metals | TDS meter (digital, reads conductivity) | $10–20 | Monthly | | **Heavy metals (lead, arsenic)** | Specific toxic contamination | Home test strips (screening only), lab analysis (accurate) | $10–30 (strips), $25–75 (lab) | Annually, or when source changes |

When to Send Samples to a Lab

Home testing handles routine monitoring. Laboratory analysis is necessary when:

  • **New water source:** Any well, spring, or surface water source being used for the first time
  • **Known contamination nearby:** Agricultural runoff, industrial discharge, mining, landfills within 1 mile
  • **After flooding:** Floodwater overwhelms wells and contaminates groundwater
  • **Infants or immunocompromised users:** Higher sensitivity to low-level contaminants
  • **Unexplained illness:** GI illness in multiple household members using the same water source
  • **Annual well testing:** The EPA recommends annual coliform and nitrate testing for all private wells

**State-certified labs** typically charge $25–150 for a basic drinking water panel (coliforms, nitrates, pH, TDS, hardness). Comprehensive panels including heavy metals, VOCs, and pesticides run $150–400. Contact your county health department for local lab referrals — many subsidize testing for private well owners.

TDS Meter Interpretation

| TDS Reading (ppm) | Water Quality | Notes | |---|---|---| | 0–50 | Very low mineral content | Distilled, RO, or rainwater | | 50–170 | Excellent drinking water | Most bottled water falls here | | 170–300 | Good | Acceptable for most uses | | 300–500 | Fair | Noticeable taste, scaling possible | | 500–1,000 | Poor | Secondary MCL exceeded; treatment recommended | | >1,000 | Unacceptable | Brackish; requires RO or distillation |

*Note: TDS measures dissolved solids by conductivity. A high TDS reading does not necessarily indicate harmful contaminants — hard water (high calcium/magnesium) reads high TDS but is safe. A low TDS reading does not confirm safety — dissolved arsenic at 50 ppb barely registers on a TDS meter but exceeds the EPA MCL of 10 ppb. TDS is a screening tool, not a safety confirmation.*

Method Comparison Matrix

| Method | Bacteria | Viruses | Protozoa (Giardia/Crypto) | Chemicals/Pesticides | Heavy Metals | TDS/Salts | Turbidity | Energy Required | Cost | Maintenance | |---|---|---|---|---|---|---|---|---|---|---| | **Boiling** | Excellent | Excellent | Excellent | No — concentrates them | No — concentrates them | No | No | High (fuel) | Low | None | | **Chlorine** | Excellent | Excellent | Partial (fails Crypto) | No | No | No | No | None | Very Low | Residual testing | | **Chlorine dioxide** | Excellent | Excellent | Excellent (4hr wait) | No | No | No | No | None | Low | None | | **Iodine** | Excellent | Excellent | Good (fails Crypto) | No | No | No | No | None | Low | None | | **Ceramic filter (0.2µm)** | Excellent | No | Excellent | Partial (carbon core only) | No | No | Good | None | Low | Scrub exterior | | **Hollow fiber (0.1µm)** | Excellent | No | Excellent | No | No | No | Good | None | Low | Backwash | | **Hollow fiber (0.02µm)** | Excellent | Excellent | Excellent | No | No | No | Good | None | Moderate | Backwash | | **Activated carbon** | No | No | No | Good (VOCs, pesticides) | Partial | No | Partial | None | Low | Replace media | | **Biosand filter** | Very Good | Good | Excellent | No | No | No | Good | None | Very Low | Swirl top sand | | **UV-C device** | Excellent | Excellent | Excellent | No | No | No | No* | Low (battery) | Moderate | Bulb replacement | | **SODIS** | Excellent | Good | Good | No | No | No | No* | None (solar) | Free | Replace bottles | | **Reverse osmosis** | Excellent | Excellent | Excellent | Good | Excellent | Excellent | Excellent | Moderate (pump) | High | Membrane replacement | | **Distillation** | Excellent | Excellent | Excellent | Partial (misses VOCs) | Excellent | Excellent | Excellent | High (heat) | Moderate | Clean boiling vessel | | **Distillation + carbon** | Excellent | Excellent | Excellent | Excellent | Excellent | Excellent | Excellent | High (heat) | Moderate | Replace carbon, clean vessel |

*\*UV requires clear water (<5 NTU) to function. Pre-filter turbid water before UV treatment.*

The matrix confirms the core principle: no single row shows "Excellent" across all columns except distillation with carbon post-filtration, and that combination carries the highest energy cost. For most situations, a two-method stack achieves safe water at lower cost — a 0.2-micron filter plus chlorine covers biological threats comprehensively, and adding activated carbon handles the most common chemical contaminants.

10. Sources

1. CDC. "A Guide to Drinking Water Treatment and Sanitation for Backcountry and Travel Use." Centers for Disease Control and Prevention, 2012. 2. CDC. "Effect of Chlorination on Inactivating Selected Pathogenic Microorganisms." CDC Waterborne Disease Prevention Branch, 2012. 3. CAWST (Centre for Affordable Water and Sanitation Technology). "Biosand Filter Manual: Design, Construction, Installation, Operation and Maintenance." Calgary, 2012. 4. EPA. "Emergency Disinfection of Drinking Water." U.S. Environmental Protection Agency, Office of Water, 2017. 5. EPA. "Ultraviolet Disinfection Guidance Manual for the Final Long Term 2 Enhanced Surface Water Treatment Rule." EPA 815-R-06-007, 2006. 6. McGuigan, K.G., Conroy, R.M., Mosler, H.-J., du Preez, M., Ubomba-Jaswa, E., Fernandez-Ibañez, P. "Solar water disinfection (SODIS): a review from bench-top to roof-top." *Journal of Hazardous Materials*, 235–236: 29–46, 2012. 7. Sobsey, M.D. "Managing Water in the Home: Accelerated Health Gains from Improved Water Supply." World Health Organization, WHO/SDE/WSH/02.07, 2002. 8. Wegelin, M., Canonica, S., Mechsner, K., Fleischmann, T., Pesaro, F., Metzler, A. "Solar water disinfection: scope of the process and analysis of radiation experiments." *Journal of Water Supply: Research and Technology—AQUA*, 43(3): 154–169, 1994. 9. WHO. "Guidelines for Drinking-water Quality." 4th edition, World Health Organization, 2017. 10. WHO. "Evaluating Household Water Treatment Options: Health-based Targets and Microbiological Performance Specifications." World Health Organization, 2011. 11. Lantagne, D.S. "Sodium Hypochlorite Dosage for Household and Emergency Water Treatment." *Journal of the American Water Works Association*, 100(8): 106–119, 2008. 12. Manz, D.H. "BioSand Water Filter Technology: Household Concrete Design." University of Calgary, 2007.

`[practical-skills]` `[beginner]`
