1. Introduction — How Groundwater Actually Works

Forget the image of underground rivers. Groundwater fills the pore spaces between grains of sand, gravel, and fractured rock. The saturated zone — where every pore is full — sits below the water table. Above it, the vadose zone holds air and water in varying proportions. A well is a hole that intersects the saturated zone and provides a pathway for water to flow to the surface.

**Aquifers** are formations permeable enough to yield useful quantities of water. Not all saturated rock qualifies. A dense shale might be saturated but release water so slowly it's useless for supply.

Two types matter for well design:

**Unconfined aquifers** sit beneath the water table with no impermeable cap. Water levels fluctuate with rainfall, season, and local pumping. Most shallow wells tap unconfined aquifers. They recharge quickly but are vulnerable to surface contamination — anything that enters the soil above eventually reaches the water.

**Confined aquifers** are sandwiched between impermeable layers (clay, unfractured rock). Water in these formations is under pressure from the weight of the overlying material and the hydraulic head of the recharge zone. Drill into a confined aquifer and water rises above the top of the formation. If the pressure is sufficient, water flows to the surface without pumping — that's an **artesian well**. True artesian flow requires the well elevation to sit below the recharge zone's hydraulic head.

The **water table** isn't flat. It roughly follows surface topography, rising under hills and approaching the surface in valleys. Where it intersects the ground, you get springs, seeps, and gaining streams. This fact drives site selection — topographic lows near water features are statistically more likely to yield shallow water.

**Static water level** is the depth to water when no pumping occurs. **Drawdown** is how far the water level drops during pumping. The ratio of pumping rate to drawdown — called **specific capacity** — is the single most important number for sizing your pump system. A well producing 10 GPM with 20 feet of drawdown (specific capacity of 0.5 GPM/ft) is a better well than one producing 10 GPM with 80 feet of drawdown.

2. Site Selection — Read the Land Before You Drill

Professional hydrogeologists use test borings, geophysical surveys, and regional geological maps. You should too, when the budget allows. But the landscape itself provides strong indicators for free.

Geological Indicators

**Alluvial deposits** — sand and gravel laid down by rivers and streams — are the most productive shallow aquifer material in most regions. Look for properties near current or historical stream channels. Old USGS topographic maps show stream paths that may have shifted.

**Glacial outwash plains** in the Upper Midwest and Northeast produce excellent sand-and-gravel aquifers at moderate depth. Glacial till (unsorted clay, sand, and boulders) is far less productive.

**Limestone and dolomite** formations can yield large volumes through solution channels and fractures, but production is unpredictable. One well hits a fracture and produces 50 GPM. The next well 100 feet away hits solid rock and produces nothing. Karst terrain (sinkholes, disappearing streams) signals productive but contamination-vulnerable limestone.

**Sandstone** formations — common across the Great Plains, Appalachians, and Gulf Coast — produce moderate yields from intergranular porosity. Generally more predictable than limestone.

**Crystalline rock** (granite, gneiss, schist) produces water only from fractures. Yields are typically low (1–5 GPM) and site selection depends entirely on intersecting fracture zones.

Vegetation Patterns

Phreatophytes — plants that tap groundwater directly — signal shallow water tables. In arid and semi-arid regions:

  • **Cottonwood, willow, and sycamore** indicate water within 10–30 feet
  • **Mesquite** can reach water at 40–60 feet but thrives where it's shallower
  • **Saltgrass and rushes** indicate water within 5–10 feet
  • **Lines of greener vegetation** across slopes often follow shallow fracture zones

In humid regions, vegetation signals are less reliable because most plants access soil moisture rather than groundwater.

Topographic Reading

  • **Valley bottoms and drainage confluences** concentrate groundwater flow
  • **Bench formations** on hillsides — flat areas on a slope — sometimes indicate a perched water table above a clay layer
  • **Spring lines** along hillsides mark where a permeable formation meets an impermeable one — drill above the spring line, and you may intercept the same water
  • **Avoid ridgetops and steep upper slopes** — the water table mirrors topography but sits deeper beneath high ground

Hydrogeological Surveys

Before committing to a $5,000–$15,000 drilled well, invest $500–$1,500 in professional site assessment:

  • **Existing well logs** — your state geological survey maintains records of every permitted well. Check neighboring properties' depth to water, yield, and geology encountered. This is free information and the single best predictor of what your well will produce.
  • **Electrical resistivity survey** — measures how easily electrical current moves through subsurface materials. Saturated sand has different resistivity than clay or dry rock. Non-invasive and covers a large area.
  • **Seismic refraction** — measures how shock waves travel through subsurface layers. Identifies depth to bedrock and major formation changes.
  • **Test boring** — a small-diameter exploratory hole. Expensive but definitive. Justified when other methods give conflicting signals or when drilling costs are high.

3. Well Types — Match the Method to the Geology

Dug Wells

The oldest method. A hand-excavated hole, typically 3–6 feet in diameter, lined with stone, brick, or concrete rings. Depths rarely exceed 30 feet. Historical importance is enormous — dug wells served humanity for thousands of years.

**Advantages:** Large diameter stores water in the casing itself, buffering against low-yield formations. Can be constructed with no specialized equipment.

**Disadvantages:** Extremely vulnerable to surface contamination. Shallow depth means susceptibility to drought. Difficult to seal properly. Not permitted for new construction in most jurisdictions. Labor-intensive and dangerous (cave-in, bad air).

**Modern relevance:** Essentially none for potable water. Some use for irrigation in developing regions.

Driven Point Wells (Sand Point Wells)

A steel point with a screened section, attached to lengths of pipe, hammered directly into the ground. The fastest and cheapest well installation possible.

**Best conditions:** Unconsolidated sand and fine gravel. Water table within 25 feet of surface. No boulders, cobbles, or cemented layers in the path.

**Limitations:** Cannot penetrate rock, dense clay, or coarse gravel. Practical depth limit of 25 feet with a suction pump (atmospheric pressure limits suction lift). Can reach 50+ feet if a deep-well hand pump or submersible pump is used, but driving pipe that deep requires significant effort and risks bending.

**Production:** Typically 1–5 GPM. Sufficient for a single household with conservation, livestock watering, or garden irrigation.

Drilled Wells

**Cable tool (percussion) drilling** — the oldest mechanical method. A heavy bit is lifted and dropped repeatedly, pulverizing rock. Cuttings are removed with a bailer (a tube with a check valve). Slow (5–25 feet per day in rock) but works in virtually any formation. The driller can observe formation changes in real time through the cuttings. Still used in some regions, particularly in fractured rock where mud rotary is problematic.

**Mud rotary drilling** — a rotating bit cuts the formation while drilling fluid (mud) circulates down the drill pipe and up the annulus, carrying cuttings to the surface and stabilizing the borehole. Fast (50–300 feet per day depending on formation). The standard method for most modern water wells. Requires a significant water supply for the mud system.

**Air rotary drilling** — compressed air replaces drilling mud as the circulating medium. Preferred in hard rock formations. Faster than cable tool, and the driller can observe water production in real time as compressed air lifts groundwater to the surface.

**Depth range:** 50 to 1,000+ feet. Most residential wells fall between 100 and 400 feet.

4. DIY Methods — Driven Point Well Construction

A driven point well is the most accessible water well for a homeowner to install without professional equipment. This section covers the complete process.

Materials Needed

| Component | Specification | Approximate Cost | |-----------|--------------|-----------------| | Drive point | 1-1/4" stainless steel or galvanized, hardened tip | $25–$50 | | Well screen | 1-1/4" x 36" stainless mesh, slot size matched to formation | $20–$40 | | Drive pipe | 1-1/4" Schedule 40 galvanized steel, 5-ft sections | $15–$25/section | | Couplings | 1-1/4" galvanized drive couplings (flush interior) | $3–$5 each | | Drive cap | 1-1/4" steel drive cap (protects threads during driving) | $8–$15 | | Pipe compound | Teflon-based thread sealant (not tape — tape shreds during driving) | $5–$10 | | Check valve | 1-1/4" brass foot valve or built into drive point | $15–$25 | | Pitcher pump or shallow well jet pump | Cast iron hand pump or 1/2 HP jet pump | $50–$300 |

**Total cost:** $150–$500 depending on depth and pump choice.

Tools Required

  • Post driver or heavy steel driver (a weighted sleeve that slides over the pipe)
  • Pipe wrenches (two, 14" or larger)
  • Step ladder (for driving pipe above reach height)
  • Level
  • Sledgehammer (backup, but a proper driver is far more effective)
  • Teflon pipe compound and rags

Step-by-Step Construction

**Step 1: Confirm suitability.** Check neighboring well logs for formation type and water table depth. Driven points only work in sand, fine gravel, or sandy loam. If your neighbor's well log shows clay, hardpan, or rock above the water table — stop. You need a different method.

**Step 2: Assemble the first section.** Thread the drive point onto the first length of well screen. Apply pipe compound to all threads — not Teflon tape, which will shred when you drive. Thread the screen onto a section of drive pipe. All couplings must be **drive couplings** with flush interior walls. Standard couplings have an interior ridge that restricts water flow and catches debris.

**Step 3: Start the hole.** If the top 2–3 feet is hard-packed or contains roots, pre-dig with a post hole digger or hand auger. Set the assembled point-screen-pipe vertically in the hole. Check plumb with a level on two sides.

**Step 4: Install the drive cap.** Thread the drive cap onto the top of the pipe. The cap protects the threads from mushrooming under impact. Never strike the pipe threads directly.

**Step 5: Begin driving.** Using the post driver or weighted sleeve, drive the pipe in steady, firm strokes. Keep the pipe plumb. If it starts to lean, it will bend at a coupling and be unrecoverable. Check plumb every 6–12 inches.

**Step 6: Add pipe sections.** When the pipe is driven to within 8–10 inches of the ground, remove the drive cap, add pipe compound to the threads, thread on the next section of pipe, replace the drive cap, and continue driving. Each joint should be tight — use two pipe wrenches, one holding and one turning.

**Step 7: Check for water.** After reaching the expected water table depth, remove the drive cap and pour water down the pipe. If the water drains away quickly, the screen is in a permeable formation. Drop a weighted string down the pipe to measure the static water level. If no water is encountered at the expected depth, drive another 5 feet and check again.

**Step 8: Develop the well.** Attach a hand pump or connect a garden hose and pump water back down the pipe under pressure, then pump it back out. Repeat. This surging action pulls fine sand away from the screen slots, creating a natural gravel pack around the screen that filters formation fines and increases flow. Pump until the water runs clear. This may take 30 minutes to several hours.

**Step 9: Install the pump.** For depths under 25 feet to static water level, a suction pump (pitcher pump or shallow-well jet pump) works. Mount the pump on a stable base, connect to the well pipe with a union fitting (for future removal), and prime.

**Step 10: Protect the wellhead.** The top of the pipe must be sealed against surface water entry. At minimum, mound soil around the base to divert runoff and install a sanitary well cap. Pour a small concrete pad around the pipe if possible.

Manual Drilling Methods

When the formation is too stiff for a driven point but you want to avoid professional drilling costs:

**Hand auger drilling** works in cohesive soils (clay, silty clay, sandy clay) to depths of 50–75 feet. A bucket auger on extensions is rotated by hand to cut and collect soil. The hole can be lined with PVC casing and screened at the bottom. Slow — expect 5–15 feet per day in favorable conditions.

**Bailer method (sludging)** uses a heavy tube with a check valve, repeatedly lifted and dropped on a rope to pulverize and collect formation material. Works in sand and soft formations. Can reach 75–100 feet with patience. Common in developing regions where it provides wells at extremely low cost.

**Jetting** uses a high-pressure water stream to wash formation material away while pipe is lowered. Effective in sand. Requires a trash pump and significant water supply. Can reach 50–100 feet in a day in ideal conditions.

5. Professional Drilling — What to Expect

The Process

A drilling contractor arrives with a truck-mounted rig, typically a mud rotary or air rotary system. The process takes 1–3 days for most residential wells.

1. **Drill the borehole** — diameter is typically 6–8 inches for residential wells. The driller logs formation changes as they go. 2. **Set casing** — steel or PVC casing lines the borehole from surface to the top of the producing formation. Casing diameter is typically 4–6 inches. 3. **Install well screen** — in unconsolidated formations, a factory-slotted screen is set opposite the producing zone. In rock, the borehole is often left open below the casing. 4. **Grout the annulus** — cement or bentonite grout fills the space between the casing and the borehole wall. This is the single most critical step for preventing surface contamination. A well without proper grouting is a direct conduit for contaminated surface water to reach the aquifer. 5. **Develop the well** — the driller surges and pumps to clear drilling fluids and formation fines. 6. **Pump test** — a sustained pumping test (typically 4–8 hours) establishes yield and drawdown.

Cost Per Foot by Region (2024 Estimates)

| Region | Cost per Foot | Typical Depth | Total Estimate | |--------|--------------|---------------|---------------| | Southeast (coastal plain) | $15–$30 | 50–200 ft | $1,500–$6,000 | | Midwest (glacial deposits) | $20–$35 | 80–250 ft | $2,000–$8,000 | | Northeast (crystalline rock) | $25–$45 | 150–400 ft | $4,000–$15,000 | | Mountain West (hard rock) | $30–$50 | 200–600 ft | $6,000–$25,000 | | Great Plains (sandstone/shale) | $20–$40 | 100–400 ft | $3,000–$12,000 | | Pacific Northwest (basalt) | $25–$45 | 100–300 ft | $3,000–$10,000 |

Prices include casing and grouting but typically exclude the pump, pressure tank, and piping to the house — add $2,000–$5,000 for a complete installation.

Casing Materials

**Steel casing** — standard for decades. Durable, strong, corrosion-prone in acidic water. Lifespan 25–50 years depending on water chemistry.

**PVC (Schedule 40 or SDR-21)** — lightweight, corrosion-proof, lower cost. Standard for wells under 300 feet in unconsolidated formations. Not suitable for deep wells or formations requiring the strength to resist collapse.

**Stainless steel** — used for screens in corrosive environments. Expensive but lasts indefinitely.

Grouting

The annular seal (grout) between the casing and the borehole wall prevents surface water from migrating down the outside of the casing. Neat cement grout or bentonite grout is tremied (pumped from the bottom up) to fill the annular space.

**Why this matters:** An ungrouted well or a well with a failed grout seal is functionally a drain that channels surface runoff directly to the aquifer. Every major study on rural groundwater contamination identifies poor annular seals as the primary pathway (Driscoll, 2008; EPA, 2017).

When Professional Drilling Is Mandatory

  • Water table deeper than 25 feet (beyond driven point and most DIY methods)
  • Any rock formation — you cannot drive or auger through rock
  • Confined aquifers requiring casing through overlying formations
  • Jurisdictions requiring licensed well drillers (most states)
  • Properties where contamination risk demands proper grouting and sealing
  • Any well intended as a primary potable water source for a permanent residence

6. Well Development — The Step That Doubles Your Yield

After drilling, the formation around the well screen is damaged. Drilling mud has invaded the pores. Fine particles clog the screen slots. The well produces a fraction of its potential.

Well development removes this damage and creates a graded filter around the screen — coarse particles nearest the screen, fines pushed back into the formation.

Surging

A plunger (surge block) is repeatedly raised and lowered inside the casing, creating alternating pressure and suction that pulls fines through the screen and pushes them back. Over many cycles, fines migrate away from the screen.

Air Lift Development

Compressed air is injected into the well through a small-diameter pipe, lifting water and sediment to the surface in powerful bursts. The intermittent surging action is highly effective. Standard practice for most professionally drilled wells.

Chemical Development

Acids (muriatic acid for calcium carbonate formations) or dispersants (polyphosphates for clay-bearing formations) break down formation damage that mechanical methods cannot clear. The chemical is placed opposite the screen, allowed to react, then pumped out. Used when mechanical development alone doesn't achieve acceptable yield.

Flow Testing and Specific Capacity

After development, a **sustained pumping test** determines the well's reliable yield.

The procedure: pump at a constant rate for a minimum of 4 hours (8+ hours preferred), measuring drawdown at regular intervals. Plot time vs. drawdown. A stabilizing curve indicates the aquifer can sustain the pumping rate. Continuously increasing drawdown means the rate exceeds the well's capacity.

**Specific capacity** = pumping rate (GPM) ÷ drawdown (feet).

Example: Pumping at 8 GPM with 16 feet of drawdown = specific capacity of 0.5 GPM/ft. If your pump is set 100 feet below static water level, and you want to maintain at least 20 feet of water above the pump, you have 80 feet of available drawdown. At 0.5 GPM/ft, the well can theoretically sustain 40 GPM — though formation boundaries and long-term depletion must be considered.

**Rule of thumb:** Size your pump for 75% of the tested yield to provide a safety margin against seasonal water table decline.

7. Pumping Systems — Match the Pump to the Well

Hand Pumps

Still practical for backup water supply, livestock, or off-grid primary use.

**Pitcher pumps** — simple suction pumps. Maximum lift of 25 feet to static water level at sea level (less at altitude). Flow rate of 2–5 GPM with effort. Affordable ($50–$150). Freeze-prone if not insulated.

**Deep well hand pumps** (e.g., Simple Pump, Bison) — positive displacement pumps on a rod assembly reaching hundreds of feet. Can lift water from 300+ feet. Cost $1,500–$3,000 installed. Reliable backup for drilled wells with submersible pumps.

Jet Pumps

Located at the surface. Two configurations:

**Shallow well jet pump** — single pipe to the well. Maximum practical suction lift of 25 feet. Simple, accessible for maintenance. 1/2 to 1 HP. Flow rates of 5–20 GPM.

**Deep well jet pump** — two pipes (pressure and suction) with a jet assembly (venturi) down in the well. Can lift water from 60–90 feet. Less efficient than submersibles (more energy wasted in friction and venturi losses). Flow rate decreases significantly with depth.

Submersible Pumps

The standard for modern drilled wells. The pump motor sits submerged in the well, pushing water to the surface through a single drop pipe.

**Advantages:** Efficient (no suction losses), quiet (underground), reliable (sealed motor, no priming issues). Can serve wells of any depth.

**Sizing considerations:**

  • **Flow rate needed:** A typical household requires 5–10 GPM for comfortable use. Irrigation demands more.
  • **Total dynamic head (TDH):** Static water level + drawdown + friction losses in pipe + pressure tank setting. A well with 150 feet of static water level, 30 feet of drawdown, 10 feet of friction loss, and a 40 PSI pressure tank (92 feet equivalent) needs a pump rated for 282 feet TDH.
  • **Motor size:** Typically 1/2 HP to 2 HP for residential. Larger for agricultural and commercial.

Solar-Powered Pumps

DC submersible pumps paired with solar panels are practical for remote locations, livestock watering, and slow-fill cistern systems.

**Key principle:** Solar pumps produce variable flow depending on sunlight intensity. Size the system to fill a storage tank during peak sun hours rather than demanding on-demand flow. A 300-watt solar array driving a DC submersible can lift 1–3 GPM from 200 feet — enough to fill 500+ gallons in a full sun day.

**Cost:** $1,500–$4,000 for pump, panels, controller, and wiring. No electrical infrastructure required. The economics improve dramatically at distances over 500 feet from the grid, where running power to a conventional pump becomes expensive.

8. Water Quality — What's in Groundwater and What to Do About It

Groundwater dissolves minerals from every formation it contacts. The result depends entirely on local geology.

Common Contaminants

**Iron (>0.3 mg/L):** Stains fixtures, laundry, and appliances orange-brown. Common in wells throughout the eastern U.S. Treatment: oxidation filters (birm, greensand), aeration, or chemical oxidation with chlorine followed by filtration.

**Manganese (>0.05 mg/L):** Causes black staining. Often accompanies iron. Same treatment methods but requires higher pH for effective oxidation.

**Hardness (calcium and magnesium, >120 mg/L as CaCO3):** Scale buildup in pipes and water heaters. Not a health risk. Treatment: water softener (ion exchange) or template-assisted crystallization (TAC) for scale prevention without salt.

**Hydrogen sulfide (rotten egg odor):** Produced by sulfate-reducing bacteria in the aquifer or by the magnesium anode in your water heater. If the smell is in cold water — it's the well. Treatment: aeration, activated carbon, chlorination, or ozone injection.

**Arsenic (>10 µg/L EPA limit):** Naturally occurring in volcanic and sedimentary formations. The USGS estimates 2.1 million U.S. domestic wells exceed the EPA limit. Odorless, tasteless, and carcinogenic with long-term exposure. Treatment: adsorptive media (iron-based), reverse osmosis, or anion exchange. Testing is the only way to know — you cannot detect arsenic by taste, smell, or appearance.

**Nitrates (>10 mg/L):** Indicates contamination from septic systems, animal waste, or fertilizer reaching the aquifer. A health risk for infants (methemoglobinemia). Common in shallow wells near agricultural activity. Treatment: reverse osmosis or anion exchange. Prevention (proper setback distances, well sealing) is more effective than treatment.

**Bacteria (total coliform, E. coli):** Presence indicates a pathway for surface contamination to enter the well. E. coli specifically indicates fecal contamination. Not a permanent aquifer condition in most cases — usually a well construction or sealing defect. Treatment: shock chlorination (see Section 9), UV disinfection for ongoing, or addressing the contamination pathway.

Why Shallow Wells Are Vulnerable

Shallow wells — whether dug, driven, or poorly sealed drilled wells — draw from unconfined aquifers with short travel times from the surface. Contaminants introduced at the surface (septic effluent, fertilizer, pesticides, animal waste, fuel spills) can reach a shallow well in days to weeks.

The soil column provides some filtration, but it's limited in both capacity and the types of contaminants it can remove. Dissolved chemicals (nitrates, pesticides) pass through soil largely unaffected. Bacteria and viruses are reduced but not eliminated in sandy soils with rapid infiltration.

Deep wells in confined aquifers have natural protection: the overlying confining layer (clay, unfractured rock) has been filtering water for decades to centuries. Contamination can still occur through improper well construction, but the aquifer itself is inherently more protected.

**Practical implication:** Every shallow well should be tested annually for bacteria and nitrates at minimum. Every well — regardless of depth — should be tested for arsenic and other naturally occurring contaminants at least once.

Testing Requirements

  • **Before use:** Full panel (bacteria, nitrates, pH, hardness, iron, manganese, arsenic, lead, total dissolved solids) from a certified lab. Cost: $100–$300.
  • **Annually:** Bacteria (total coliform and E. coli) and nitrates. Cost: $30–$75.
  • **After any event:** flooding, nearby construction, changes in taste/odor/appearance, septic system work — retest the full panel.

State health departments and cooperative extension offices often provide low-cost testing. Some states offer free testing for specific contaminants.

9. Maintenance — Keeping the Well Safe and Productive

Annual Inspection Checklist

1. **Well cap/seal:** Inspect for cracks, gaps, insect entry, or missing bolts. The cap must be a vermin-proof, watertight sanitary well cap — not a loose-fitting cover. 2. **Casing condition:** Check for visible cracks or corrosion above ground level. Older steel casings deteriorate from the outside; corrosion at the surface line is common. 3. **Surface grading:** The ground around the well should slope away in all directions to prevent pooling. Settle or erosion around the casing requires re-grading and potentially re-grouting. 4. **Electrical connections:** Inspect the wire from the pressure switch to the well for damage, rodent chewing, or moisture in junction boxes. 5. **Pressure tank:** Check air precharge (should be 2 PSI below the cut-in pressure). Waterlogged tanks (no air cushion) cause rapid cycling that destroys pump motors. 6. **Water quality test:** Collect the annual bacteria and nitrate sample. 7. **Flow rate:** Time how long it takes to fill a 5-gallon bucket. Compare to previous years. Declining flow rate indicates well screen fouling, pump wear, or declining water table.

Pump Replacement Schedule

Submersible pumps: 10–25 years depending on water quality (sand and sediment shorten life dramatically), cycling frequency, and motor quality. Budget for replacement at year 15.

Jet pumps: 8–15 years. Easier to service because the motor is above ground.

Pressure tanks: 10–15 years for bladder tanks. Check precharge annually.

Shock Chlorination Procedure

When bacteria are detected, or annually as preventive maintenance:

1. **Calculate well volume:** Well volume (gallons) = 1.5 × depth of water in the well (in feet) for a 6-inch casing. Example: 200 feet of water column in a 6-inch well = 300 gallons. 2. **Determine chlorine dose:** Use 3 cups of unscented household bleach (5.25–8.25% sodium hypochlorite) per 100 gallons of well water. For the example above: 9 cups. 3. **Remove the well cap.** Pour the calculated amount of bleach directly into the well. 4. **Recirculate.** Connect a garden hose from an outdoor faucet back to the well opening. Run the pump and recirculate water back into the well for 15–30 minutes. This mixes the chlorine throughout the well column and into the formation around the screen. 5. **Run every faucet** in the house until you smell chlorine, then shut them off. 6. **Wait 12–24 hours.** Do not use water during this period. The chlorine needs contact time. 7. **Flush the system.** Run water from an outdoor faucet (away from septic system and landscaping) until chlorine odor is gone. This may take 30 minutes to several hours depending on well volume and yield. 8. **Retest.** Wait 5–7 days after flushing, then collect a bacteria sample. If bacteria are still present, the contamination pathway hasn't been sealed — address the well construction defect before repeating chlorination.

10. Legal — Permits, Setbacks, and Abandonment

Well regulations vary significantly by state and even by county. These are general frameworks — check your specific jurisdiction before drilling.

Permits

Most states require a well drilling permit before any work begins. Some exempt driven point wells or wells for non-potable use. The permit process typically requires:

  • Property owner's name and address
  • Well location on a site plan
  • Intended use (domestic, irrigation, livestock)
  • Name of the licensed driller (if required)
  • Proposed depth and construction specifications

Many states require the driller to submit a completed well log after construction, documenting formations encountered, casing depth, grouting, static water level, and tested yield. These logs become public record and are invaluable for neighboring property owners planning wells.

Setback Distances (Typical Minimums)

| Feature | Minimum Distance from Well | |---------|--------------------------| | Septic tank | 50 feet | | Septic drain field | 100 feet | | Property line | 10–25 feet | | Building foundation | 10 feet | | Fuel storage tank | 100 feet | | Animal feedlot | 100–200 feet | | Sewer line | 50 feet | | Surface water body | 25–50 feet | | Road or driveway | 10–25 feet |

These are minimums. Greater distances provide greater protection. In sandy soils with rapid infiltration, double the setback from septic systems.

Well Abandonment

When a well is no longer used, it must be properly sealed to prevent it from becoming a contamination conduit. An abandoned, unsealed well is the largest single threat to groundwater quality on any property (EPA, 2017).

Proper abandonment requires: 1. Removing the pump and drop pipe 2. Filling the well with neat cement grout or bentonite from bottom to top (not just capping it) 3. Cutting the casing below ground surface 4. Filing an abandonment report with the state

Cost: $500–$2,000 depending on depth and diameter. Many states have cost-share programs for sealing abandoned wells, particularly in areas with known groundwater contamination.

Buying rural property? Walk the fencelines and old building sites. Unmarked, abandoned wells are common on properties with any agricultural history.

11. Sources

1. Driscoll, F.G. *Groundwater and Wells*. 3rd ed. Johnson Screens, 2008. 2. Midwest Plan Service. *Private Water Systems Handbook*. MWPS-14, 2009. 3. U.S. Geological Survey. "Groundwater Use in the United States." Water-Use Report, 2015. 4. U.S. Environmental Protection Agency. "Protect Your Drinking Water: Information on Private Water Wells." EPA 816-K-17-001, 2017. 5. U.S. Geological Survey. "Arsenic in Groundwater of the United States." Fact Sheet 2019-3060, 2019. 6. National Ground Water Association. "Manual of Water Well Construction Practices." NGWA, 2014. 7. Roscoe Moss Company. *Handbook of Ground Water Development*. Wiley, 1990. 8. Heath, R.C. "Basic Ground-Water Hydrology." USGS Water-Supply Paper 2220, 1983. 9. U.S. Centers for Disease Control and Prevention. "Well Testing." Private Ground Water Wells, 2020. 10. National Environmental Services Center. "Well Maintenance and Rehabilitation." Tech Brief, West Virginia University, 2017.

`[practical-skills]` `[facility-design]` `[advanced]`
